Features:

stable performance, strong anti-interference ability, free from the influence of temperature, humidity and wind.

Compact and light, can be used for serial port and upper machine debugging, can be programmed debugging, power consumption Low, small beam Angle.

Should use:

agricultural irrigation, sewage treatment, hydrology and water conservancy, urban road bridge water monitoring.

Maximum range :15m/30m/45m

Fine degrees: ±3mm/±5mm/±10mm

Process connection: M105*2 screw/t-type support/flange

The environment temperature (-40 ~ 70 ℃)

Process pressure: atmospheric pressure

Reduplication: ±1mm

Antenna material: PP

Frequency range: 26GHz

Signal output: RS485/Modbus protocol (6~26V) DC

Protection class: IP68

Advantages: maintenance free, non-contact measurement, no wear and tear, accurate measurement, free of medium,

Process and environmental constraints.
